Diatomite earth functional filler is a versatile additive that enhances the performance of various materials and products. It boasts a range of commendable properties, including lightweight texture, softness, high porosity, sound insulation, heat and acid resistance, large surface area, and excellent chemical stability.Thanks to these characteristics, diatomite functional filler is widely used across multiple industries as a performance-enhancing additive, improving the functionality and quality of numerous materials and end products.
Source factory, high quality and low price
Low density, high whiteness, Low vorticity, high purity
Typical Physical & Chemical Properties
Grade | TP200 | TP450 | TP750 | TP950 | TH31 | TH33 | TH35 | TH37 | TH39 |
Colour | Pink | Pink | Pink | Pink | white | white | White | White | White |
GEB rightness | - | - | - | - | 91 | 90 | 90 | 90 | 89 |
Moisture (%) | 0.21 | 0.21 | 0.22 | 0.23 | 0.22 | 0.22 | 0.23 | 0.23 | 0.25 |
sieve analysis(%)+200 Mesh | 0.5 | tr | tr | tr | tr | tr | tr | tr | tr |
sieve analysis(%)+325 Mesh | 0.9 | 1 | 0.1 | tr | 8.5 | 1 | 0.3 | 0.1 | tr |
Median Particle Diameter(um) | 28.6 | 15.8 | 10 | 5.8 | 25.2 | 22.6 | 16.3 | 10.2 | 7 |
PH | 6.8 | 6.8 | 6.9 | 6.9 | 9 | 9 | 9.3 | 9.3 | 9.5 |
1、Tyler Screen;+200 mesh= > 74 microns、+325 mesh= > 47 microns | |||||||||
Product Grades | SiO2(%) | Al2O3(%) | FeO3(%) | CaO(%) | MgO(%) | Loss on lgnition (%) | Refractive Index | ||
TP200 Thru TP750 Grades | 90.7 | 3.18 | 1.28 | 0.47 | 0.36 | 0.23 | 1.43 | ||
TH31 Thru TH39 Grades | 89.8 | 3.22 | 1.22 | 0.46 | 0.33 | 0.22 | 1.46 | ||
The properties reported represent typical values. The values are supplied as a technical service. For important health and safety information, please see the MSDS. | 中国硅藻土制造商 CHINA DIATOMITE MANUFACTURE | ||||||||
10 years of focus on diatomaceous earth research and developme
Official certification, professional after sales service.
Providing one-stop solutions
Full intimate service - to meet the practical needs of all cust
What are the advantages of diatomite earth functional filler? | |
Diatomite earth functional filler is a high-quality additive widely used in industries such as fertilizers, coatings, plastics, rubber abrasives, ceramics, polishing materials, and centrifugal casting release agents.The filler is produced from diatomite ore with an SiO₂ content exceeding 85%. The ore undergoes drying, crushing, pre-sorting, and calcination in a dynamic rotary kiln without any additional materials. The calcination process is conducted at temperatures between 850–1150°C. The final product is refined using classifiers and further processed with an air-jet mill and grading equipment.Storage & Handling Requirements:Must be protected from rain, moisture, sunlight, and corrosive substances.Should be stored on pallets or moisture-proof felt boards to avoid direct contact with the ground.Stacking height must not exceed 30 layers.During transportation, measures must be taken to prevent moisture exposure, and it must not be shipped alongside polluting, corrosive, or sharp metal objects.Handling must be done carefully—avoid dropping from heights or using metal hooks to prevent packaging damage.This filler ensures high purity, thermal stability, and chemical resistance, making it an ideal choice for enhancing material performance in various industrial applications. | |
How To Order? | Can You Supply Sample For Test ? |
1: Plese tell us the detailed technical parameters you needed | Yes, the sample is free. |
2: Then we choose the exact type diatomite filter aid . | |
3: Pls tell us the packing requirements,quantityand other request. | When Will Make A Delivery? |
4:Then we answer these questions and give a best offer. | Delivery time - Stock order: 3 days after receipt of the full payment.- Other order: 15 days after of the deposit. |
What Are Your Core Advantage? | |
1. Source factory, own mine, stable supply of core raw materials for 30 years. | |
2, The new self-developed low temperature washing storage process, lower product density, longer filtration cycle; The whiteness of the filler higher, the particle size of the product is more uniform, and the vortex value is less. | |
3. The only large enterprise in China that uses natural gas as a heat source for production, we always take environmental protection as our own responsibility and are committed to achieving sustainable development while protecting the environment. | |
What Is Your Capacity? | |
The production capacity of our current diatomaceous earth filter aid is 60,000 tons/year, the production capacity diatomaceous earth filler is 2.5 tons/year, the production capacity of natural diatomaceous earth constant temperature drying product is 15,000 tons/year, the total production capacity of 90,000 tons/year. |
