Calcined Diatomite Filter Aid

Calcined Diatomite Filter Aid

Produced through precision calcination of natural diatomite, our calcined diatomaceous earth filter aid features exceptional porosity exceeding 95%, combining superior adsorption capacity with optimal permeability. Specifically engineered for high-precision filtration in pharmaceutical and chemical industries, this advanced material delivers unmatched performance.

Technical Advantages:Ultra-Pure Filtration.Uniform microporous structure (0.1-30μm) achieves 99.9% fluid purity.Effectively captures suspended solids, colloids and microorganisms.Certified pharmaceutical-grade safety with zero leaching risks.Enhanced Process Efficiency.Exceptional chemical stability (acid/alkali resistant).Maintains solution integrity without pH alteration.Compatible with plate-and-frame filters and centrifugal systems.Reduces system resistance by 30%, extends filter life by 40%.Sustainable Operation.Easy cake removal and recovery system35% reduction in solid waste generation.Supports circular economy in industrial production.Performance Highlights: Medical-grade purity assurance. 50% higher flow rates vs conventional media. Validated for cGMP applications. Reduces total filtration costs by 25-30%.

Ideal for critical processes requiring both filtration excellence and environmental responsibility, our calcined diatomaceous earth sets new standards for industrial separation technology. Complete technical specifications and validation data available upon request.

Inquiry Now

Production process introduction

Source factory, high quality and low price

Product technical indicators

Low density, high whiteness, Low vorticity, high purity

Grade	TD21	TD23	TD25	TD27	TS505	TS507	TS509	TS516	TS518	TS527	TS528	TS529	TS637	TS639
Colour	Pink	Pink	Pink	Pink	white	white	white	White	White	White	White	White	White	White
Permeability(Darcy)	0.05	0.13	0.22	0.31	1.4	1.9	2.5	3.6	4.5	5.5	7	8.5	10	16.5
Tap density (g/cm3)	0.45	0.45	0.45	0.45	0.46	0.46	0.46	0.47	0.47	0.47	0.47	0.47	0.48	0.48
Wet Densityc(g/cm3)	0.37	0.37	0.37	0.37	0.35	0.35	0.35	0.34	0.34	0.33	0.33	0.33	0.33	0.32
sieve analysis（%）	0.4	0.6	0.9	1.2	2.5	2.8	3	6.3	7.5	10.5	15.5	15.8	19	25
+150 Mesh	0.4	0.6	0.9	1.2	2.5	2.8	3	6.3	7.5	10.5	15.5	15.8	19	25
Median Particle Diameter(um)	15.2	17.8	20.6	22.8	25	28.8	30.5	32.5	37.2	40.8	45.8	50.2	60.7	72.6
PH	6.8	6.8	6.9	7	8.5	8.5	8.5	9	9	9.2	9.2	9.2	9.5	9.5
1、Tyler Screen;+150 mesh= > 105 microns 2、Note: Permeability (Darcy) is tested by CHINA method.
Product Grades	SiO2(%)		Al2O3(%)		FeO3(%)		CaO(%)		MgO(%)		Loss on lgnition (%)		Refractive Index
TD21 Thru TD27 Grades	90.5		3.15		1.35		0.48		0.38		0.25		1.43
TS505 Thru TS639 Grades	89.9		3.26		1.23		0.45		0.35		0.22		1.46
The properties reported represent typical values. The values are supplied as a technical service. For important health and safety information, please see the MSDS.											中国硅藻土制造商 CHINA DIATOMITE MAN UFACTURER
											中国硅藻土制造商 CHINA DIATOMITE MAN UFACTURER

Company introduction

10 years of focus on diatomaceous earth research and developme

Honor And Qualification

Official certification, professional after sales service.

Logistics and packageing

Full intimate service - to meet the practical needs of all cust

Everything you need to know

What Are The Advantages Of Calcined Diatomite Filter Aid?
The Calcined Diatomite filter aid enhances natural diatomite properties through high-temperature calcination, establishing itself as an essential material for precision industrial filtration. Its defining characteristic is an ultra-high porosity (85%+), enabling precise retention of 0.1-30μm suspended particles, colloids, and microorganisms - delivering 60% greater filtration efficiency than standard diatomite. This makes it particularly suitable for demanding applications like injectable drug purification and chemical catalyst recovery. Key Benefits:Exceptional Purity Performance.Pharmaceutical-grade certified with zero leachables. Chemically inert, resistant to strong acids/alkalis.Guarantees 99.9%+ filtrate purity.Maintains stability in high-temperature/high-viscosity media.Operational Excellence. Low-density/high-permeability design.30% reduction in system resistance.25%+ energy savings. 40% extended filter media lifespan.Compatible with plate-and-frame and rotary vacuum filters. Sustainable Advantages.Loose filter cake structure for easy removal.35% reduction in solid waste. Supports recycling and reuse.Fully biodegradable and renewable.Industrial Applications: Pharmaceutical sterile filtration. Petrochemical catalyst recovery. Biopharmaceutical processing. High-precision chemical separation. This advanced filter aid combines three critical advantages: superior particle retention, energy-efficient operation, and cross-industry adaptability. By significantly reducing carbon footprint while maintaining filtration excellence, calcined diatomaceous earth supports the transition toward low-carbon, sustainable industrial processes. Complete technical validation data and environmental impact reports available for professional evaluation. Performance Guarantee:Consistent flow rates under extreme conditions.Validated for continuous operation.Reduces total cost of ownership by 30-35%.Complies with global environmental regulations.

How To Order?	Can You Supply Sample For Test ?
1: Plese tell us the detailed technical parameters you needed	Yes, the sample is free.
2: Then we choose the exact type diatomite filter aid .
3: Pls tell us the packing requirements,quantityand other request.	When Will Make A Delivery?
4：Then we answer these questions and give a best offer.	Delivery time - Stock order: 3 days after receipt of the full payment.- Other order: 15 days after of the deposit.

What Are Your Core Advantage?
1. Source factory, own mine, stable supply of core raw materials for 30 years.
2, The new self-developed low temperature washing storage process, lower product density, longer filtration cycle; The whiteness of the filler higher, the particle size of the product is more uniform, and the vortex value is less.
3. The only large enterprise in China that uses natural gas as a heat source for production, we always take environmental protection as our own responsibility and are committed to achieving sustainable development while protecting the environment.

What Is Your Capacity?
The production capacity of our current diatomaceous earth filter aid is 60,000 tons/year, the production capacity diatomaceous earth filler is 2.5 tons/year, the production capacity of natural diatomaceous earth constant temperature drying product is 15,000 tons/year, the total production capacity of 90,000 tons/year.
