Diatomite For Filtration

Diatomite For Filtration

Diatomite for filtration is produced from natural fossilized diatoms through graded calcination processes, featuring a porosity exceeding 80%. Specially designed for precision solid-liquid separation in industries such as food, pharmaceuticals, and chemicals, its uniform microporous structure efficiently captures suspended particles, colloids, and microorganisms ranging from 0.5 to 30 μm, significantly improving filtrate clarity. Certified for pharmaceutical-grade safety, it poses no risk of leaching contamination.With strong chemical inertness, acid/alkali resistance, and no alteration of solution properties, this filter aid is compatible with equipment such as plate-and-frame filter presses and centrifugal separators. Its low fouling characteristics reduce system resistance by 40%, extend filter element lifespan by 30%, and produce loose, easily removable filter cakes, cutting solid waste discharge by 50%. Combining high-efficiency filtration with circular economy benefits, it is an optimal material for sustainable industrial production.

Inquiry Now

Production process introduction

Source factory, high quality and low price

Product technical indicators

Low density, high whiteness, Low vorticity, high purity

Grade	TD21	TD23	TD25	TD27	TS505	TS507	TS509	TS516	TS518	TS527	TS528	TS529	TS637	TS639
Colour	Pink	Pink	Pink	Pink	white	white	white	White	White	White	White	White	White	White
Permeability(Darcy)	0.05	0.13	0.22	0.31	1.4	1.9	2.5	3.6	4.5	5.5	7	8.5	10	16.5
Tap density (g/cm3)	0.45	0.45	0.45	0.45	0.46	0.46	0.46	0.47	0.47	0.47	0.47	0.47	0.48	0.48
Wet Densityc(g/cm3)	0.37	0.37	0.37	0.37	0.35	0.35	0.35	0.34	0.34	0.33	0.33	0.33	0.33	0.32
sieve analysis（%）	0.4	0.6	0.9	1.2	2.5	2.8	3	6.3	7.5	10.5	15.5	15.8	19	25
+150 Mesh	0.4	0.6	0.9	1.2	2.5	2.8	3	6.3	7.5	10.5	15.5	15.8	19	25
Median Particle Diameter(um)	15.2	17.8	20.6	22.8	25	28.8	30.5	32.5	37.2	40.8	45.8	50.2	60.7	72.6
PH	6.8	6.8	6.9	7	8.5	8.5	8.5	9	9	9.2	9.2	9.2	9.5	9.5
1、Tyler Screen;+150 mesh= > 105 microns 2、Note: Permeability (Darcy) is tested by CHINA method.
Product Grades	SiO2(%)		Al2O3(%)		FeO3(%)		CaO(%)		MgO(%)		Loss on lgnition (%)		Refractive Index
TD21 Thru TD27 Grades	90.5		3.15		1.35		0.48		0.38		0.25		1.43
TS505 Thru TS639 Grades	89.9		3.26		1.23		0.45		0.35		0.22		1.46
The properties reported represent typical values. The values are supplied as a technical service. For important health and safety information, please see the MSDS.											中国硅藻土制造商 CHINA DIATOMITE MAN UFACTURER
											中国硅藻土制造商 CHINA DIATOMITE MAN UFACTURER

Company introduction

10 years of focus on diatomaceous earth research and developme

Honor And Qualification

Official certification, professional after sales service.

Logistics and packageing

Full intimate service - to meet the practical needs of all cust

Everything you need to know

What Are The Advantages Of Diatomite For Filtration？
Processed through graded calcination of natural fossilized diatoms, our diatomaceous earth filter aid features over 80% porosity and is specifically engineered for precision solid-liquid separation in food, pharmaceutical, and chemical industries. The material's uniform microporous structure effectively captures 0.5-30μm suspended particles, colloids and microorganisms, significantly improving filtrate clarity while meeting pharmaceutical-grade safety certifications with zero leaching risks. Technical Advantages:Optimized Filtration Performance.Precisely engineered pore distribution. 99.5%+ particle retention efficiency.Maintains solution chemistry and pH balance.Certified for GMP-compliant production.Enhanced Operational Efficiency.40% reduction in system resistance. 30% extended filter element lifespan.Low-fouling characteristics.Compatible with multiple filtration platforms:Plate-and-frame filters.Centrifugal separation systems.Rotary vacuum filters Sustainable Benefits.Easily removable filter cakes.50% reduction in solid waste generation.Supports material recovery and reuse.Lowers overall production costs by 25-35%. Industry Applications: Beverage clarification. Pharmaceutical pre-filtration. Chemical catalyst recovery. Industrial wastewater treatment. This advanced filter aid combines exceptional filtration precision with environmental responsibility, making it the ideal choice for manufacturers seeking to improve process efficiency while meeting sustainability goals. The material's balanced performance characteristics - including its validated chemical stability, consistent flow rates and waste reduction capabilities - deliver reliable results across demanding industrial applications. Complete technical specifications and compliance documentation available for quality assurance purposes.

How To Order?	Can You Supply Sample For Test ?
1: Plese tell us the detailed technical parameters you needed	Yes, the sample is free.
2: Then we choose the exact type diatomite filter aid .
3: Pls tell us the packing requirements,quantityand other request.	When Will Make A Delivery?
4：Then we answer these questions and give a best offer.	Delivery time - Stock order: 3 days after receipt of the full payment.- Other order: 15 days after of the deposit.

What Are Your Core Advantage?
1. Source factory, own mine, stable supply of core raw materials for 30 years.
2, The new self-developed low temperature washing storage process, lower product density, longer filtration cycle; The whiteness of the filler higher, the particle size of the product is more uniform, and the vortex value is less.
3. The only large enterprise in China that uses natural gas as a heat source for production, we always take environmental protection as our own responsibility and are committed to achieving sustainable development while protecting the environment.

What Is Your Capacity?
The production capacity of our current diatomaceous earth filter aid is 60,000 tons/year, the production capacity diatomaceous earth filler is 2.5 tons/year, the production capacity of natural diatomaceous earth constant temperature drying product is 15,000 tons/year, the total production capacity of 90,000 tons/year.
