Diatomite Filter Aid for Beer

Diatomite Filter Aid for Beer

The diatomite filter aid for beer is refined from premium-grade natural diatomaceous earth. Its porous structure provides an ultra-large specific surface area, enabling efficient retention of yeast, proteins, and impurities. With uniform particle size distribution and strong permeability, it significantly enhances filtration speed and clarity while preserving the original flavor of beer.This diatomite filter aid is suitable for plate-and-frame and candle filtration systems, offering high operational stability and easy filter cake removal, which reduces filter media consumption by 30%. Certified by ISO standards, it is eco-friendly and non-toxic, helping breweries optimize production efficiency and product quality.

Inquiry Now

Production process introduction

Source factory, high quality and low price

Product technical indicators

Low density, high whiteness, Low vorticity, high purity

Grade	TD21	TD23	TD25	TD27	TS505	TS507	TS509	TS516	TS518	TS527	TS528	TS529	TS637	TS639
Colour	Pink	Pink	Pink	Pink	white	white	white	White	White	White	White	White	White	White
Permeability(Darcy)	0.05	0.13	0.22	0.31	1.4	1.9	2.5	3.6	4.5	5.5	7	8.5	10	16.5
Tap density (g/cm3)	0.45	0.45	0.45	0.45	0.46	0.46	0.46	0.47	0.47	0.47	0.47	0.47	0.48	0.48
Wet Densityc(g/cm3)	0.37	0.37	0.37	0.37	0.35	0.35	0.35	0.34	0.34	0.33	0.33	0.33	0.33	0.32
sieve analysis（%）	0.4	0.6	0.9	1.2	2.5	2.8	3	6.3	7.5	10.5	15.5	15.8	19	25
+150 Mesh	0.4	0.6	0.9	1.2	2.5	2.8	3	6.3	7.5	10.5	15.5	15.8	19	25
Median Particle Diameter(um)	15.2	17.8	20.6	22.8	25	28.8	30.5	32.5	37.2	40.8	45.8	50.2	60.7	72.6
PH	6.8	6.8	6.9	7	8.5	8.5	8.5	9	9	9.2	9.2	9.2	9.5	9.5
1、Tyler Screen;+150 mesh= > 105 microns 2、Note: Permeability (Darcy) is tested by CHINA method.
Product Grades	SiO2(%)		Al2O3(%)		FeO3(%)		CaO(%)		MgO(%)		Loss on lgnition (%)		Refractive Index
TD21 Thru TD27 Grades	90.5		3.15		1.35		0.48		0.38		0.25		1.43
TS505 Thru TS639 Grades	89.9		3.26		1.23		0.45		0.35		0.22		1.46
The properties reported represent typical values. The values are supplied as a technical service. For important health and safety information, please see the MSDS.											中国硅藻土制造商 CHINA DIATOMITE MAN UFACTURER
											中国硅藻土制造商 CHINA DIATOMITE MAN UFACTURER

Company introduction

10 years of focus on diatomaceous earth research and developme

Honor And Qualification

Official certification, professional after sales service.

Logistics and packageing

Full intimate service - to meet the practical needs of all cust

Everything you need to know

What Are The Advantages Of Diatomite Filter Aid For Beer？
Natural & High-Efficiency Filtration The beer-grade diatomaceous earth filter aid is made from high-purity natural diatomite ore. Through calcination and grading processes, it forms a stable porous structure with a specific surface area of 20-60 m²/g. It effectively captures particles ranging from 0.1 to 40 μm, including yeast, colloidal proteins, and fine impurities. Its water permeability is enhanced by 40%, significantly shortening filtration cycles and reducing energy consumption.

How To Order?	Can You Supply Sample For Test ?
1: Plese tell us the detailed technical parameters you needed	Yes, the sample is free.
2: Then we choose the exact type diatomite filter aid .
3: Pls tell us the packing requirements,quantityand other request.	When Will Make A Delivery?
4：Then we answer these questions and give a best offer.	Delivery time - Stock order: 3 days after receipt of the full payment.- Other order: 15 days after of the deposit.

What Are Your Core Advantage?
1. Source factory, own mine, stable supply of core raw materials for 30 years.
2, The new self-developed low temperature washing storage process, lower product density, longer filtration cycle; The whiteness of the filler higher, the particle size of the product is more uniform, and the vortex value is less.
3. The only large enterprise in China that uses natural gas as a heat source for production, we always take environmental protection as our own responsibility and are committed to achieving sustainable development while protecting the environment.

What Is Your Capacity?
The production capacity of our current diatomaceous earth filter aid is 60,000 tons/year, the production capacity diatomaceous earth filler is 2.5 tons/year, the production capacity of natural diatomaceous earth constant temperature drying product is 15,000 tons/year, the total production capacity of 90,000 tons/year.
