Sewage Treatment Of Diatomaceous Earth

Sewage Treatment Of Diatomaceous Earth

Sewage treatment of diatomaceous earth is refined from premium diatomite ore through proprietary thermal activation technology, achieving exceptional adsorption capabilities with ≥88% SiO₂ content, ≥80% porosity, 50-70m²/g specific surface area, and precisely calibrated 0.5-15μm pore structure for optimal contaminant targeting. This advanced filtration medium delivers:Heavy metal ion removal efficiency >95% (including Pb²⁺, Cd²⁺)，≥85% COD reduction for organic pollutants，Significant turbidity and BOD reduction，Engineered for harsh environments with acid/alkali resistance (pH 2-12) and biological corrosion resistance, it's ideal for both industrial effluent and municipal wastewater treatment, compatible with press filters, sedimentation tanks and other standard equipment.Operational Advantages:Ultra-low dosage (0.1-0.5% by volume)，40% sludge volume reduction，30% faster dewatering performance

，Environmentally certified non-toxic solution，Sustainable disposal options (solidification landfill or resource recovery)，Combining cost-efficiency with broad system compatibility, Shengtai's diatomaceous earth solution enables reliable compliance with discharge standards while supporting ecological restoration initiatives. The product's unique pore architecture and surface chemistry provide superior contaminant capture across diverse wastewater treatment applications.

Inquiry Now

Production process introduction

Source factory, high quality and low price

Product technical indicators

Low density, high whiteness, Low vorticity, high purity

Grade	TD21	TD23	TD25	TD27	TS505	TS507	TS509	TS516	TS518	TS527	TS528	TS529	TS637	TS639
Colour	Pink	Pink	Pink	Pink	white	white	white	White	White	White	White	White	White	White
Permeability(Darcy)	0.05	0.13	0.22	0.31	1.4	1.9	2.5	3.6	4.5	5.5	7	8.5	10	16.5
Tap density (g/cm3)	0.45	0.45	0.45	0.45	0.46	0.46	0.46	0.47	0.47	0.47	0.47	0.47	0.48	0.48
Wet Densityc(g/cm3)	0.37	0.37	0.37	0.37	0.35	0.35	0.35	0.34	0.34	0.33	0.33	0.33	0.33	0.32
sieve analysis（%）	0.4	0.6	0.9	1.2	2.5	2.8	3	6.3	7.5	10.5	15.5	15.8	19	25
+150 Mesh	0.4	0.6	0.9	1.2	2.5	2.8	3	6.3	7.5	10.5	15.5	15.8	19	25
Median Particle Diameter(um)	15.2	17.8	20.6	22.8	25	28.8	30.5	32.5	37.2	40.8	45.8	50.2	60.7	72.6
PH	6.8	6.8	6.9	7	8.5	8.5	8.5	9	9	9.2	9.2	9.2	9.5	9.5
1、Tyler Screen;+150 mesh= > 105 microns 2、Note: Permeability (Darcy) is tested by CHINA method.
Product Grades	SiO2(%)		Al2O3(%)		FeO3(%)		CaO(%)		MgO(%)		Loss on lgnition (%)		Refractive Index
TD21 Thru TD27 Grades	90.5		3.15		1.35		0.48		0.38		0.25		1.43
TS505 Thru TS639 Grades	89.9		3.26		1.23		0.45		0.35		0.22		1.46
The properties reported represent typical values. The values are supplied as a technical service. For important health and safety information, please see the MSDS.											中国硅藻土制造商 CHINA DIATOMITE MAN UFACTURER
											中国硅藻土制造商 CHINA DIATOMITE MAN UFACTURER

Company introduction

10 years of focus on diatomaceous earth research and developme

Honor And Qualification

Official certification, professional after sales service.

Logistics and packageing

Full intimate service - to meet the practical needs of all cust

Everything you need to know

What Are The Advantages Of Sewage Treatment Of Diatomaceous Earth？
1.High-Efficiency Pollutant Removal Heavy Metal Adsorption: The porous structure of diatomaceous earth achieves over 98% adsorption efficiency for heavy metal ions through ion exchange and surface complexation, particularly effective for hard-to-degrade organic compounds. 2.Multifunctional Synergistic Treatment Decolorization & Deodorization: Removes >90% of dye wastewater color while adsorbing odor-causing substances like ammonia nitrogen and hydrogen sulfide. Microbial Carrier: The porous surface provides attachment sites for microorganisms, enabling biofilm reactor construction to enhance biochemical treatment efficiency. 3.Eco-Friendly & Sustainable Naturally Non-Toxic: Sourced from fossilized diatoms, free from heavy metals and harmful chemicals, compliant with GB/T 24251-2009 environmental standards. Regenerable & Recyclable: Can be reactivated for repeated use, minimizing waste. 4.Cost-Effective Performance Low-Cost & Easy Operation: Requires no complex equipment—can be directly dosed or integrated with existing processes (e.g., sedimentation tanks, sand filters). Broad Applicability: Suitable for municipal sewage, textile dyeing wastewater, electroplating effluent, papermaking black liquor, and more. Conclusion: With its high adsorption capacity, multifunctional synergy, and eco-economic benefits, diatomaceous earth is an ideal alternative to traditional chemical agents. It demonstrates exceptional advantages in heavy metal remediation and resource recovery, aligning with China’s "Dual Carbon" strategy and holding significant potential for widespread adoption.

How To Order?	Can You Supply Sample For Test ?
1: Plese tell us the detailed technical parameters you needed	Yes, the sample is free.
2: Then we choose the exact type diatomite filter aid .
3: Pls tell us the packing requirements,quantityand other request.	When Will Make A Delivery?
4：Then we answer these questions and give a best offer.	Delivery time - Stock order: 3 days after receipt of the full payment.- Other order: 15 days after of the deposit.

What Are Your Core Advantage?
1. Source factory, own mine, stable supply of core raw materials for 30 years.
2, The new self-developed low temperature washing storage process, lower product density, longer filtration cycle; The whiteness of the filler higher, the particle size of the product is more uniform, and the vortex value is less.
3. The only large enterprise in China that uses natural gas as a heat source for production, we always take environmental protection as our own responsibility and are committed to achieving sustainable development while protecting the environment.

What Is Your Capacity?
The production capacity of our current diatomaceous earth filter aid is 60,000 tons/year, the production capacity diatomaceous earth filler is 2.5 tons/year, the production capacity of natural diatomaceous earth constant temperature drying product is 15,000 tons/year, the total production capacity of 90,000 tons/year.
