Industrial Diatomaceous Earth

Industrial Diatomaceous Earth

Our premium Industrial Diatomaceous Earth is precision-engineered from high-purity diatomite through advanced calcination processes, delivering exceptional performance with ≥88% SiO₂ content, ≥85% porosity, and an extensive 40-80 m²/g surface area. The multi-level pore structure (0.1-50μm) is specifically designed to handle complex industrial fluids, achieving >98% retention rates for heavy metal ions, oil contaminants, and micron-scale suspended particles.This robust filtration medium demonstrates outstanding chemical resistance (pH 1-14) and thermal stability (450℃), with superior compressive strength that prevents structural collapse during prolonged operation. Available in customizable 20-400 mesh particle sizes, it seamlessly integrates with diverse industrial applications including petrochemical catalyst recovery, metallurgical flux purification, paint waste removal, and wastewater treatment - delivering 30% improved filtration efficiency while reducing waste residue by 35%.Environmentally superior with minimal leaching and zero pollution, our solution enables sustainable resource recovery through metal extraction and construction material regeneration, offering over 20% total cost reduction. Combining precision filtration, extreme durability, and full lifecycle sustainability, this industrial-grade diatomaceous earth empowers cleaner production processes and more efficient separation technologies across multiple industries.

Inquiry Now

Production process introduction

Source factory, high quality and low price

Product technical indicators

Low density, high whiteness, Low vorticity, high purity

Grade	TD21	TD23	TD25	TD27	TS505	TS507	TS509	TS516	TS518	TS527	TS528	TS529	TS637	TS639
Colour	Pink	Pink	Pink	Pink	white	white	white	White	White	White	White	White	White	White
Permeability(Darcy)	0.05	0.13	0.22	0.31	1.4	1.9	2.5	3.6	4.5	5.5	7	8.5	10	16.5
Tap density (g/cm3)	0.45	0.45	0.45	0.45	0.46	0.46	0.46	0.47	0.47	0.47	0.47	0.47	0.48	0.48
Wet Densityc(g/cm3)	0.37	0.37	0.37	0.37	0.35	0.35	0.35	0.34	0.34	0.33	0.33	0.33	0.33	0.32
sieve analysis（%）	0.4	0.6	0.9	1.2	2.5	2.8	3	6.3	7.5	10.5	15.5	15.8	19	25
+150 Mesh	0.4	0.6	0.9	1.2	2.5	2.8	3	6.3	7.5	10.5	15.5	15.8	19	25
Median Particle Diameter(um)	15.2	17.8	20.6	22.8	25	28.8	30.5	32.5	37.2	40.8	45.8	50.2	60.7	72.6
PH	6.8	6.8	6.9	7	8.5	8.5	8.5	9	9	9.2	9.2	9.2	9.5	9.5
1、Tyler Screen;+150 mesh= > 105 microns 2、Note: Permeability (Darcy) is tested by CHINA method.
Product Grades	SiO2(%)		Al2O3(%)		FeO3(%)		CaO(%)		MgO(%)		Loss on lgnition (%)		Refractive Index
TD21 Thru TD27 Grades	90.5		3.15		1.35		0.48		0.38		0.25		1.43
TS505 Thru TS639 Grades	89.9		3.26		1.23		0.45		0.35		0.22		1.46
The properties reported represent typical values. The values are supplied as a technical service. For important health and safety information, please see the MSDS.											中国硅藻土制造商 CHINA DIATOMITE MAN UFACTURER
											中国硅藻土制造商 CHINA DIATOMITE MAN UFACTURER

Company introduction

10 years of focus on diatomaceous earth research and developme

Honor And Qualification

Official certification, professional after sales service.

Logistics and packageing

Full intimate service - to meet the practical needs of all cust

Everything you need to know

Advantages Of Industrial-grade Diatomite
1.High-Precision Adsorption & Separation：Multi-level pore structure (0.1-50 μm) and high porosity (≥85%) precisely target impurities in industrial feed liquids.Suspended solids retention rate > 98%, heavy metal ion (e.g., Pb²⁺, Cr³⁺) removal rate ≥ 95%, and oil adsorption capacity up to 0.8 g/g, significantly improving product purity. 2.Extreme Environment Resistance:Withstands strong acids and alkalis (pH 1-14) and high temperatures up to 450°C. Compressive strength > 2 MPa, making it ideal for harsh conditions like petrochemical catalysis and metallurgical smelting.Long-term stability outperforms traditional filter media. 3.Energy & Cost Efficiency:High-permeability design increases filtration efficiency by 30% and reduces filter cake resistance by 40%. Waste residue reduced by 35%, lowering overall energy consumption by 20-30% and extending equipment maintenance cycles. 4.Broad Application Compatibility:Customizable particle sizes (20-400 mesh) for diverse industrial needs, including:Petrochemical catalyst recovery,Paint residue removal,Metallurgical flux purification,Industrial wastewater treatment,Compatible with pressure filtration, centrifugation, and vacuum systems. 5.Sustainable Resource Recycling：Filter residue can be regenerated (e.g., precious metal extraction, building material production).Calcination process produces zero pollution emissions, reducing carbon footprint by 25%.Supports corporate ESG (Environmental, Social, and Governance) goals. 6.Long-Term Economic Benefits：High mechanical strength (wear rate < 0.3%) and anti-clogging properties.Reduces total lifecycle costs by 30% and improves return on investment (ROI). Conclusion Industrial-grade diatomite, with its "precision separation + extreme durability" core advantages, empowers industries to achieve high-efficiency production, resource recycling, and low-carbon transformation, addressing critical challenges in high-pollution and high-energy-consumption sectors.

How To Order?	Can You Supply Sample For Test ?
1: Plese tell us the detailed technical parameters you needed	Yes, the sample is free.
2: Then we choose the exact type diatomite filter aid .
3: Pls tell us the packing requirements,quantityand other request.	When Will Make A Delivery?
4：Then we answer these questions and give a best offer.	Delivery time - Stock order: 3 days after receipt of the full payment.- Other order: 15 days after of the deposit.

What Are Your Core Advantage?
1. Source factory, own mine, stable supply of core raw materials for 30 years.
2, The new self-developed low temperature washing storage process, lower product density, longer filtration cycle; The whiteness of the filler higher, the particle size of the product is more uniform, and the vortex value is less.
3. The only large enterprise in China that uses natural gas as a heat source for production, we always take environmental protection as our own responsibility and are committed to achieving sustainable development while protecting the environment.

What Is Your Capacity?
The production capacity of our current diatomaceous earth filter aid is 60,000 tons/year, the production capacity diatomaceous earth filler is 2.5 tons/year, the production capacity of natural diatomaceous earth constant temperature drying product is 15,000 tons/year, the total production capacity of 90,000 tons/year.
