Water Treatment Of Diatomaceous Earth

Water Treatment Of Diatomaceous Earth

Diatomaceous earth for water treatment is an eco-friendly filtration material derived from natural fossilized diatoms. is an eco-friendly filtration material derived from natural fossilized diatoms. Characterized by its high porosity and exceptionally large specific surface area, it demonstrates outstanding adsorption capacity for suspended solids, colloids, and heavy metal ions in water, making it widely applicable in municipal water supply, industrial wastewater treatment, and swimming pool purification systems.The material's micron-scale porous structure enables deep filtration of impurities above 0.5μm, significantly improving water clarity while effectively reducing COD and turbidity levels. Through activation and modification processes, the treated diatomaceous earth achieves excellent chemical stability, exhibiting strong resistance to acid/alkali corrosion with no leaching risks, fully complying with drinking water safety standards.Compatible with pressure filters and sand filter tanks, this filtration medium offers easy operation and simple filter cake removal, allowing for repeated use to reduce operational costs. Combining high-efficiency contaminant removal with environmentally friendly characteristics, diatomaceous earth represents an optimal solution for advanced water purification applications across various industries.

Inquiry Now

Production process introduction

Source factory, high quality and low price

Product technical indicators

Low density, high whiteness, Low vorticity, high purity

Grade	TD21	TD23	TD25	TD27	TS505	TS507	TS509	TS516	TS518	TS527	TS528	TS529	TS637	TS639
Colour	Pink	Pink	Pink	Pink	white	white	white	White	White	White	White	White	White	White
Permeability(Darcy)	0.05	0.13	0.22	0.31	1.4	1.9	2.5	3.6	4.5	5.5	7	8.5	10	16.5
Tap density (g/cm3)	0.45	0.45	0.45	0.45	0.46	0.46	0.46	0.47	0.47	0.47	0.47	0.47	0.48	0.48
Wet Densityc(g/cm3)	0.37	0.37	0.37	0.37	0.35	0.35	0.35	0.34	0.34	0.33	0.33	0.33	0.33	0.32
sieve analysis（%）	0.4	0.6	0.9	1.2	2.5	2.8	3	6.3	7.5	10.5	15.5	15.8	19	25
+150 Mesh	0.4	0.6	0.9	1.2	2.5	2.8	3	6.3	7.5	10.5	15.5	15.8	19	25
Median Particle Diameter(um)	15.2	17.8	20.6	22.8	25	28.8	30.5	32.5	37.2	40.8	45.8	50.2	60.7	72.6
PH	6.8	6.8	6.9	7	8.5	8.5	8.5	9	9	9.2	9.2	9.2	9.5	9.5
1、Tyler Screen;+150 mesh= > 105 microns 2、Note: Permeability (Darcy) is tested by CHINA method.
Product Grades	SiO2(%)		Al2O3(%)		FeO3(%)		CaO(%)		MgO(%)		Loss on lgnition (%)		Refractive Index
TD21 Thru TD27 Grades	90.5		3.15		1.35		0.48		0.38		0.25		1.43
TS505 Thru TS639 Grades	89.9		3.26		1.23		0.45		0.35		0.22		1.46
The properties reported represent typical values. The values are supplied as a technical service. For important health and safety information, please see the MSDS.											中国硅藻土制造商 CHINA DIATOMITE MAN UFACTURER
											中国硅藻土制造商 CHINA DIATOMITE MAN UFACTURER

Company introduction

10 years of focus on diatomaceous earth research and developme

Honor And Qualification

Official certification, professional after sales service.

Logistics and packageing

Full intimate service - to meet the practical needs of all cust

Everything you need to know

What Are The Advantages Of Water Treatment Of Diatomaceous Earth?
Water treatment of diatomaceous earth has emerged as a highly effective solution in water purification, leveraging its unique physical and eco-friendly properties. The material's natural porous structure delivers exceptional adsorption capacity, effectively capturing suspended particles, colloids, and heavy metal ions ranging from 0.5 to 50μm, while rapidly reducing water turbidity and COD levels. Compared to conventional filtration media, its porosity exceeding 80% enhances filtration efficiency by 40%, simultaneously decreasing backwashing frequency to significantly reduce energy consumption and operational costs. Through high-temperature activation and modification processes, the treated diatomaceous earth achieves remarkable chemical stability with zero toxic substance leaching, fully complying with China's GB5749 drinking water hygiene standards. When applied in municipal water supply and industrial wastewater treatment systems, it not only provides deep water purification but also maintains essential mineral balance, ensuring both water safety and ecological compatibility. Its lightweight characteristics enable seamless integration with various equipment including sand filters and membrane separation systems, offering operational flexibility and easy sludge recovery to support resource recycling. With broad applicability, diatomaceous earth performs reliably in challenging scenarios such as highly polluted wastewater and swimming pool circulation systems, demonstrating excellent resistance to acids, alkalis, and high-temperature environments while maintaining long-term stability. By combining superior contaminant removal, environmental safety, and multi-scenario adaptability, diatomaceous earth continues to provide dependable support for water purification projects, effectively contributing to green and sustainable development objectives.

How To Order?	Can You Supply Sample For Test ?
1: Plese tell us the detailed technical parameters you needed	Yes, the sample is free.
2: Then we choose the exact type diatomite filter aid .
3: Pls tell us the packing requirements,quantityand other request.	When Will Make A Delivery?
4：Then we answer these questions and give a best offer.	Delivery time - Stock order: 3 days after receipt of the full payment.- Other order: 15 days after of the deposit.

What Are Your Core Advantage?
1. Source factory, own mine, stable supply of core raw materials for 30 years.
2, The new self-developed low temperature washing storage process, lower product density, longer filtration cycle; The whiteness of the filler higher, the particle size of the product is more uniform, and the vortex value is less.
3. The only large enterprise in China that uses natural gas as a heat source for production, we always take environmental protection as our own responsibility and are committed to achieving sustainable development while protecting the environment.

What Is Your Capacity?
The production capacity of our current diatomaceous earth filter aid is 60,000 tons/year, the production capacity diatomaceous earth filler is 2.5 tons/year, the production capacity of natural diatomaceous earth constant temperature drying product is 15,000 tons/year, the total production capacity of 90,000 tons/year.
